Abrasive Belt Stainless Steel Polishing Machine
OUYIGANG is one of the companies engaged in the production of stainless steel surface processing machinery and equipment.
Over the years committed to the research and development of the production of stainless steel CNC sanding machine (No.4), stainless steel polishing machine, stainless steel snowflake drawing machine (HL), stainless steel CNC short grain machine (SB), stainless steel mirror steel machine (8K), grinding machine, grain machine, cleaning machine, CNC lamination machine, winding machine, unwinding machine and other equipment.
The company's products are mainly used in high-end home appliances, tableware, kitchenware, bathroom, elevator, building decoration, hardware products, precision electronics and various new energy water heaters and many other industries.
The company has excellent production equipment, advanced technology, perfect inspection and considerate service, based on the Pearl River Delta, radiation at home and abroad, to serve the majority of end customers.
- OUYIGANG
- FOSHAN
- One Months
- 1 Set/ Month
- Information
- Video
Abrasive Belt Stainless Steel Polishing Machine
The polishing of coils and sheets is one of the most value added operations offered by service centers. Perfect machinery is the key to success in every business, OUYIGANG grinding/ polishing machines are very easy to achieved Matt, Hair -Line, Satin, No.4,No.6 finish. OUYIGANG Metal Surface Polishing Machines can be applied to the top surface of coils and sheets. We are the leading company in the metal processing equipment , our machine cover more than 70% of the Chinese market and is going to meet the worldwide challenge with its extraordinary performance and innovative technology.
Basic specification for the machine:
Belt abrasive station | No.4 | / | Hairline |
Brush abrasive station | / | SB | / |
System | Wet roller grinding | Wet roller brushing | Wet roller grinding |
No. of working unit | 2-3 grinding heads | 2-4 polishing heads | 2-3 grinding heads |
Machine weight | Appro 13T | 11T | 13T |
Working width | 900,1250,1500mm, customized available | ||
Sheet size | 1250X2500mm；1550X3000mm；customized available | ||
Sheet thickness min / max | 0.3-4mm | 0.3-4mm | 0.3-4mm |
Roller dimensions(Od X width) | 300mm | 350mm | 250mm |
Abrasive belt width | Depending on the sheet width | ||
Abrasive belt length | 2620mm | 2620mm | |
Speed of the line | 6-25m/min | 6-25m/min | 6-25m/min |
Processing capability
No.4 finish
The basic sheet selection is to be of 2B or BA sheet and should be preferably polished with 150#,180# abrasive belt. The application verticals of this finish to name a few are in cookware, furniture, elevator, architectural decoration, revolving door, exterior decoration etc,.
Hairline finsh
The basic sheet selection should preferably be of No.4 satin surface stainless steel sheet and should be subjected to polish with 150#/240# abrasive belt. The application verticals of this finish to name a few are in elevator, architecture decoration, revolving door, furniture, home appliance, auto sector, exterior decoration, etc,.
Scotch Brite-Satin finish
The basic sheet selection should preferably be of No.4 satin surface stainless steel sheet and should be subjected to polish with abrasive wheels or pads. . The application verticals of this finish to name a few are in architecture decoration, elevators and escalators, furniture, etc,.
No.6 finish
These finishes are produced using rotating cloth mops (tampico fibre,muslin or linen) which are loaded with abrasive paste.The finish depends on how fine an a abrasive is used and the uniformity and finish of the original surface. The finish as a non directional texture of varing reflectivity.Satin blend is an example of such a finish.
No.7 finish
This is a buffed finish having a high degree of reflectivity.It is produced by progressively using finer and finer abrasives and finishing with buffing compounds. Some fine scratches may remain from the original starting surface.
No.8 true mirror finish
This is produced in an equivalent manner to a No.7 finish, the final operation being done with extremely fine buffing compounds. The final surface is blemish free with a high degree of image clarity and is the true mirror finish.
No.9 super mirror finish
Very high degree of reflectivity, brilliant, smooth finish produced by polishing with progressively finer grit abrasives then buffing. Super mirror creates light and space. Best for design, decoration and architecture.
Multi head brushing station, “all in one line ” equipment with No.4—No.6 , Scotch-Brite , Hairline finish
Control by PLC complete with touch screen
Most of the inside construction is made of tempered stainless steel
Horizontal axis rotating and oscillating system
Soft, bright and homogeneous surface appearance
oil and water mixed ,wet type processing
Adjustable brushing pressure
Adjustable brush speed
Easy abrasives brush roller replacement
Adjustable conveyor speed (belt / roller)
Different brush grits combinations are possible to perform different surface treatment
Emergency security switch
Reversal conveyor speed for emergency control
Packaging & Shipping
Packaging: all of the machine, equipment and spare parts spray the rustproof oil, cover with oil paper and plastic film.
Shipping: arrange technical workers to load the machine with crane , fixed the machine to the container with strong steel rope, and guarantee your machine shipped to your port without any human causing damage.
